Lesson 5: Bringing the pieces together to build the App

In the previous lessons, we have setup:

• A Runtime action to perform CRUD operations for todo items.
• CreateTodoList React component to create a todo list.
• Todo React component to display and update a todo item.
• TodoList React component to display todo items.

In this lesson, we'll build the actual App to manage todo lists. We'll create the React component file under web-src/src/components/ and simply name it App.js.

We'll start by importing our components:

Copy
import { CreateTodoList } from './CreateTodoList';
import { TodoList } from './TodoList';
Copied to your clipboard
import { CreateTodoList } from './CreateTodoList';
import { TodoList } from './TodoList';

Import React Spectrum components

This component will make use of several React Spectrum components:

• Provider the container of the React Spectrum application.
• defaultTheme the default React Spectrum theme.
• ProgressCircle the loading indicator.
• View a generic container.
• Flex for the layout of the loading indicator.
• Grid for the layout of the todo lists.
• repeat a helper function for Grid.

Copy
import { Provider, defaultTheme, View, Flex, Grid, repeat, ProgressCircle } from '@adobe/react-spectrum';
Copied to your clipboard
import { Provider, defaultTheme, View, Flex, Grid, repeat, ProgressCircle } from '@adobe/react-spectrum';

Component property

The component will accept a single property, the ims information that we'll pass to the Runtime action for authentication.

Copy
function App({ ims }) {
  // ...
}
Copied to your clipboard
function App({ ims }) {
  // ...
}

Component state values

On initialization, the App will display a loading indicator while fetching the todo lists. For the loading indicator and the todo lists, we'll use the State hook useState again.

Copy
const [isLoading, setIsLoading] = useState(true);
const [todoList, setTodoList] = useState([]);
Copied to your clipboard
const [isLoading, setIsLoading] = useState(true);
const [todoList, setTodoList] = useState([]);

Action function callbacks

To communicate with the Runtime action, we'll create a simple utility function with 2 parameters:

• The expected CRUD operation.
• The sent data e.g. todo list name or todo object.

First make sure to import the config.json which contains the URL to your Runtime action.

Copy
import actions from '../config.json';
Copied to your clipboard
import actions from '../config.json';

Then inside the App, we'll define the utility function with the ims information.

Copy
const action = async (operation, body = {}) => {
  const res = await fetch(actions['todolist'], {
    method: 'POST',
    headers: {
      'Content-Type': 'application/json',
      'x-gw-ims-org-id': ims.org,
      authorization: `Bearer ${ims.token}`
    },
    body: JSON.stringify({
      operation,
      ...body
    })
  });

  return await res.json();
};
Copied to your clipboard
const action = async (operation, body = {}) => {
  const res = await fetch(actions['todolist'], {
    method: 'POST',
    headers: {
      'Content-Type': 'application/json',
      'x-gw-ims-org-id': ims.org,
      authorization: `Bearer ${ims.token}`
    },
    body: JSON.stringify({
      operation,
      ...body
    })
  });

  return await res.json();
};

Finally, we'll use the utility function inside callback functions that we're going to pass as prop to the components we have built in the previous lessons.

Copy
const onCreateTodoList = async (name) => {
  if (!todoList.find(({ name: todoListName }) => name === todoListName)) {
    setTodoList([{ name, todos: [] }, ...todoList]);

    console.log(await action('create', { name }));
  }
};

const onDeleteTodoList = async (name) => {
  setTodoList(todoList.filter(({ name: toDeleteName }) => name !== toDeleteName));

  console.log(await action('delete', { name }));
};

const onUpdateTodoList = async (name, todo) => {
  console.log(await action('update', { name, todo }));
};
Copied to your clipboard
const onCreateTodoList = async (name) => {
  if (!todoList.find(({ name: todoListName }) => name === todoListName)) {
    setTodoList([{ name, todos: [] }, ...todoList]);

    console.log(await action('create', { name }));
  }
};

const onDeleteTodoList = async (name) => {
  setTodoList(todoList.filter(({ name: toDeleteName }) => name !== toDeleteName));

  console.log(await action('delete', { name }));
};

const onUpdateTodoList = async (name, todo) => {
  console.log(await action('update', { name, todo }));
};

Loading indicator

By default, we'll be showing a ProgressCircle to indicate that the App is loading. Meanwhile, the todo lists will be fetched using an Effect Hook which will run only once when the App is mounted.

Once we've retrieved the todo lists, we're updating the todo list state and set the loading state to false.

Copy
useEffect(() => {
  (async () => {
    const { todoList } = await action('read');
    if (todoList) {
      setTodoList(todoList);
      setIsLoading(false);
    }
  })();
}, []);
Copied to your clipboard
useEffect(() => {
  (async () => {
    const { todoList } = await action('read');
    if (todoList) {
      setTodoList(todoList);
      setIsLoading(false);
    }
  })();
}, []);

With React Conditional Rendering, we can easily define what will be rendered based on the isLoading state. Once the state value is set to false, we'll display the CreateTodoList from lesson 3 and pass the onCreateTodoList callback function as prop.

Copy
<View elementType="main" minHeight="100vh">
  {isLoading ? (
    <Flex alignItems="center" justifyContent="center" height="100vh">
      <ProgressCircle size="L" aria-label="Loading…" isIndeterminate />
    </Flex>
  ) : (
    <View height="size-800" marginY="size-400">
      <CreateTodoList onCreate={onCreateTodoList} />
      ...
    </View>
  )}
</View>
Copied to your clipboard
<View elementType="main" minHeight="100vh">
  {isLoading ? (
    <Flex alignItems="center" justifyContent="center" height="100vh">
      <ProgressCircle size="L" aria-label="Loading…" isIndeterminate />
    </Flex>
  ) : (
    <View height="size-800" marginY="size-400">
      <CreateTodoList onCreate={onCreateTodoList} />
      ...
    </View>
  )}
</View>

Rendering todo lists

Next to CreateTodoList, we'll also render the todo lists. For that, we're going to use the React Spectrum Grid component. Similarly to the previous lesson, we'll iterate over the todoList array using the map() function to render each item as TodoList component.

Copy
<Grid
  columns={repeat('auto-fit', 'size-3400')}
  autoRows="size-6000"
  justifyContent="center"
  gap="size-200">
  {todoList.map((list) => (
    <TodoList key={list.name} todoList={list} onDelete={onDeleteTodoList} onUpdate={onUpdateTodoList} />
  ))}
</Grid>
Copied to your clipboard
<Grid
  columns={repeat('auto-fit', 'size-3400')}
  autoRows="size-6000"
  justifyContent="center"
  gap="size-200">
  {todoList.map((list) => (
    <TodoList key={list.name} todoList={list} onDelete={onDeleteTodoList} onUpdate={onUpdateTodoList} />
  ))}
</Grid>

Since todo list names are unique, we're using the name as key prop. We're also passing the todoList object and the onDelete, onUpdate function callbacks as props to the TodoList component.

Full component

Finally, we'll just wrap the whole App inside the React Spectrum Provider with the default theme set to light which corresponds to the Experience Cloud Shell main content theme.

Copy
<Provider theme={defaultTheme} colorScheme={`light`}>
...
</Provider>
Copied to your clipboard
<Provider theme={defaultTheme} colorScheme={`light`}>
...
</Provider>

See the full component code here.
