Lesson 2: Spectrum CSS

Spectrum CSS is the CSS-only implementation of Spectrum.

Using Spectrum CSS

The preferred method of using Spectrum CSS relies on custom properties to swap out variables for different themes and colorstops. This has the lowest bundle size and the simplest usage, but is incompatible with < IE 11.

Each component is released on npm as a separate, individually versioned package inside of the @spectrum-css org.

Building a simple form using Spectrum CSS

This example will show how to build a simple form using Spectrum CSS.

To get started, install the following components:

npm install @spectrum-css/vars @spectrum-css/typography @spectrum-css/page @spectrum-css/icon @spectrum-css/button @spectrum-css/textfield @spectrum-css/checkbox @spectrum-css/fieldlabel

Then simply include the stylesheets:

Copied to your clipboard
<!-- Include global variables first -->
<link rel="stylesheet" href="node_modules/@spectrum-css/vars/dist/spectrum-global.css">


<!-- Include only the scales your application needs -->
<link rel="stylesheet" href="node_modules/@spectrum-css/vars/dist/spectrum-medium.css">
<link rel="stylesheet" href="node_modules/@spectrum-css/vars/dist/spectrum-large.css">


<!-- Include only the colorstops your application needs -->
<link rel="stylesheet" href="node_modules/@spectrum-css/vars/dist/spectrum-light.css">


<!-- Include index-vars.css for all components you need -->
<link rel="stylesheet" href="node_modules/@spectrum-css/page/dist/index-vars.css">
<link rel="stylesheet" href="node_modules/@spectrum-css/typography/dist/index-vars.css">
<link rel="stylesheet" href="node_modules/@spectrum-css/button/dist/index-vars.css">
<link rel="stylesheet" href="node_modules/@spectrum-css/textfield/dist/index-vars.css">
<link rel="stylesheet" href="node_modules/@spectrum-css/fieldlabel/dist/index-vars.css">

Then, make sure you've included the relevant classes to choose which scale and colorstop you want:

Copied to your clipboard
<html lang="en" dir="ltr" class="spectrum spectrum--medium spectrum--light">

Then include the Adobe Fonts e.g. using your Typekit id. Visit https://typekit.com/account/kits to create one.

Copied to your clipboard
<!-- mge7bvf is the Typekit id. Please don't reuse, it's not meant for production. -->
<script src="https://use.typekit.net/mge7bvf.js"></script>
<script>window.Typekit.load()</script>

Then you can start using components by copy/pasting their code from the documentation. For our example, we'll use following components:

Resulting in the following code:

Copied to your clipboard
<!-- .spectrum-Typography will apply margins to all typography components like headings. -->
<main class="spectrum-Typography">
  <h3 class="spectrum-Heading spectrum-Heading--M" id="login-label">Login</h3>
  <form class="spectrum-Form spectrum-Form--labelsAbove" aria-labelledby="login-label" id="login">
    <div class="spectrum-Form-item">
      <label for="email" class="spectrum-Form-itemLabel spectrum-FieldLabel--left">Email</label>
      <div class="spectrum-Form-itemField">
        <input class="spectrum-Textfield" id="email" placeholder="Enter your email" name="email"/>
      </div>
    </div>
    <div class="spectrum-Form-item">
      <label class="spectrum-Form-itemLabel spectrum-FieldLabel--left" for="password">Password</label>
      <div class="spectrum-Form-itemField">
        <input class="spectrum-Textfield" type="password" placeholder="Enter your password" id="password">
      </div>
    </div>
    <div class="spectrum-Form-item">
      <div class="spectrum-Form-itemField">
        <div class="spectrum-FieldGroup">
          <label class="spectrum-Checkbox">
            <input type="checkbox" class="spectrum-Checkbox-input">
            <span class="spectrum-Checkbox-box">
              <svg class="spectrum-Icon spectrum-UIIcon-CheckmarkSmall spectrum-Checkbox-checkmark" focusable="false" aria-hidden="true">
                <use xlink:href="#spectrum-css-icon-CheckmarkSmall"></use>
              </svg>
            </span>
            <span class="spectrum-Checkbox-label">Remember me</span>
          </label>
        </div>
      </div>
    </div>
    <button form="login" type="submit" class="spectrum-Button spectrum-Button--cta">
        <span class="spectrum-Button-label">Login</span>
    </button>
  </form>
</main>

The checkbox component requires the spectrum-css-icon-CheckmarkSmall SVG icon. It's recommended to use loadicons to load the spectrum-css-icons.svg collection which includes that icon:

Copied to your clipboard
<script src="node_modules/loadicons/index.js"></script>
<script>
  loadIcons('node_modules/@spectrum-css/icon/dist/spectrum-css-icons.svg');
</script>

Spectrum supports the :focus-visible property but you'll have to include a script to make it work across all browsers:

Copied to your clipboard
npm i @adobe/focus-ring-polyfill

then include the script:

Copied to your clipboard
<script src="node_modules/@adobe/focus-ring-polyfill/index.js"></script>

Now when you tab into a button for example, you should see a focus-ring appearing around the button:

focus-ring

Finally ...

If you stick all pieces together, you should see following:

app

That's quite some work therefore Spectrum CSS should only be used by implementations of Spectrum, or very simple applications that only need things like typography, textfields etc.

Adobe maintains separate JavaScript libraries written with React, Angular, and web components that use Spectrum CSS to create fully interactive Spectrum components. These libraries support font loading, SVG icons and have built-in accessibility and internationalization. We recommend using them over Spectrum CSS.
