Embed SDK Generate Image tutorial

Learn how to implement the Generate Image module using the Adobe Express Embed SDK.

Introduction

Welcome to this hands-on tutorial! We'll walk you through implementing the powerful Generate Image module of the Adobe Express Embed SDK. By the end, your integration will be able to use all its new V2 features, from the Community Wall to Rich Preview and Thumbnail actions. As a bonus, we'll implement a Custom version of the Community Wall, so that you can showcase your own images instead of Firefly's publicly available gallery.

What you'll learn

By completing this tutorial, you'll gain practical skills in:

  • Implementing the Generate Image module with the Adobe Express Embed SDK.
  • Using the new V2 features of the Generate Image module.
  • Implementing the Custom Community Wall.

What you'll build

You'll build a simple, JavaScript-based web application that allows users to generate images from text prompts using the Generate Image module of the Adobe Express Embed SDK.

Generate image

Prerequisites

Before you start, make sure you have:

  • An Adobe account (use your existing Adobe ID or create one for free)
  • API credentials from the Adobe Developer Console (Get credentials)
  • Basic knowledge of HTML, CSS, and JavaScript
  • Node.js installed on your development machine (v20.19.0 or higher)
  • A text editor or IDE of your choice

1. Set up the project

1.1 Clone the sample

You can start by cloning the Embed SDK Generate Image sample from GitHub and navigating to the project directory.

Copied to your clipboard
git clone https://github.com/AdobeDocs/embed-sdk-samples.git
cd embed-sdk-samples/code-samples/tutorials/embed-sdk-generate-image

The project will have a structure like this:

Copied to your clipboard
.
├── package.json             📦 Project configuration
├── vite.config.js           🔧 Build configuration
└── src
    ├── images               📷 Images for the Custom Community Wall
    │   └── ...
    ├── index.html           🌐 UI container
    ├── main.js              💻 Embed SDK logic
    ├── community-wall.js    🖼️ Custom Community Wall logic
    └── style.css            🎨 CSS styles

1.2 Set up the API key

Locate the src/.env file and replace the placeholder string in the VITE_API_KEY with your Embed SDK API Key:

Copied to your clipboard
VITE_API_KEY="your-api-key-here!"

1.3 Install dependencies

Install the dependencies by running the following commands:

Copied to your clipboard
npm install
npm run start

The web application will be served at localhost:5555 on a secure HTTPS connection—which is always required for any Embed SDK integration. Open your browser and navigate to this address to see it in action.

Generate image integration UI

When clicking the Generate Image button, the Adobe Express Generate Image module will launch, showing the Community Wall—optionally, populated with your own pictures. Users can browse the gallery, select an image, and use its prompt as a starting point for their own generation.

The sample project will handle the file transfer between Adobe Express and the web page hosting it, and the generated image will be displayed in lieu of the placeholder.

Generate image thumbnail

2. Load the Generate Image v2 module

You can just read the existing code in the sample, but it's always best to learn by doing! We suggest following along and typing the code in—even small mistakes can lead to important discoveries.

The sample project is a simple web application built with Vite, which takes care of the entire local HTTPS setup and hot reloading.

2.1 Import the Embed SDK

In this tutorial, we'll focus on the JavaScript side of things first—the HTML content is not overly important. Open the project in your code editor of choice. In main.js, remove everything below the Spectrum import statements—we'll rebuild it from scratch.

Copied to your clipboard
// main.js


// Import theme and typography styles from Spectrum Web Components
import "@spectrum-web-components/styles/typography.css";
import "@spectrum-web-components/theme/express/theme-light.js";
import "@spectrum-web-components/theme/express/scale-medium.js";
import "@spectrum-web-components/theme/sp-theme.js";


// Import Spectrum Web Components
import "@spectrum-web-components/button/sp-button.js";
import "@spectrum-web-components/button-group/sp-button-group.js";
import "@spectrum-web-components/divider/sp-divider.js";
import "./style.css";

The imports above allow us to style our web application with Spectrum Web Components and the Adobe Express theme. Let's begin working in main.js by importing the Embed SDK:

Copied to your clipboard
// main.js
//... previous imports ...


// Import the Adobe Express Embed SDK
await import("https://cc-embed.adobe.com/sdk/v4/CCEverywhere.js");
console.log("CCEverywhere loaded", window.CCEverywhere);

2.2 Initialize the Embed SDK

When the Embed SDK is imported, a CCEverywhere object is globally available and must be initialized. There are two sets of parameters that you can pass as option objects:

  • Host Information: containing the API key, Application name, etc.
  • Configuration: optional settings, like locale, delayed sign-in, etc.
Copied to your clipboard
// main.js
//... previous imports ...


// 👀 Required parameters to initialize the Embed SDK
const hostInfo = {
  clientId: import.meta.env.VITE_API_KEY,
  appName: "Embed SDK Sample",
};


// Optional parameters
const configParams = { /* ... */ };


// Initialize the Adobe Express Embed SDK
// Destructure the `module` property only
const { module } = await window.CCEverywhere.initialize(
  hostInfo,
  configParams
);

The hostInfo object is required: the clientId contains your API Key (here, retrieved by Vite from the .env file) and the appName.

2.3 Load the module

The asynchronous CCEverywhere.initialize() method returns an object with three properties. Here, we destructure the module only, because it is the entry point to the createImageFromText() method. In the next section, we'll learn how to use it to launch the Generate Image experience.

Copied to your clipboard
module.createImageFromText({ /* ... */ });

3. Launch the Generate Image experience

The createImageFromText() method expects three optional parameters:

Copied to your clipboard
// module.createImageFromText() function signature


const appConfig       = { /* ... */ }; // Text to Image experience
const exportConfig    = { /* ... */ }; // Export options
const containerConfig = { /* ... */ }; // SDK container


module.createImageFromText(appConfig, exportConfig, containerConfig);

In this tutorial, we'll focus on the appConfig object; you can look at the Full Editor tutorial for more details on the other two parameters.

3.1 Enable the v2 experience

The first thing we need to do is to enable the v2 experience.

Copied to your clipboard
// main.js
//... previous code ...


const appConfig = {
  appVersion: "2",
  // ...
};

3.2 Toggle selected v2 features

Among all the new features, here we'll focus on the following ones:

  • Community Wall, the endless gallery of images generated by other users that are displayed when the experience is launched.
  • Rich Preview, a larger preview of the generated image in the thumbnail.
  • Thumbnail actions, a dropdown menu in the thumbnail to allow users to further edit the generated image.
Copied to your clipboard
// main.js
//... previous code ...


const appConfig = {
  appVersion: "2",
  featureConfig: {
    "community-wall": true, // 👈 Enable the Community Wall
  },
  thumbnailOptions: [
    "rich-preview",         // 👈 Enable the Rich Preview
    "edit-dropdown",        // 👈 Enable the Edit dropdown
  ],
  editDropdownOptions: [    // 👇 Set the options for the Edit dropdown
    { option: "add-effects" },
    { option: "remove-background" },
    { option: "apply-adjustment" },
    { option: "insert-object" },
    { option: "remove-object" },
  ],
};

Generate image community wall

3.3 Connect the UI with the Embed SDK logic

The last step is to connect the UI in index.html, a simple button and an image placeholder, with the Embed SDK logic in main.js.

In the UI:

  • The generateBtn button is used to launch the Generate Image experience.
  • An <img> element is used to display the generated image when it's ready.

In main.js:

  • The module.createImageFromText() method is called when the generateBtn button is clicked.
  • A callbacks object is used to handle the experience lifecycle.
    • onPublish() is called when the user publishes the generated image. The publishParams object contains a projectId and an asset object with the generated image data, that we've used to set the src attribute of the <img> element.
  • The exportConfig array is used to set the export options available to the user. Here, we've added two buttons:
    • download: it allows users to download the generated image.
    • save-modified-asset: it saves the generated image and passes it to the onPublish() callback.
Copied to your clipboard
// Import theme and typography styles from Spectrum Web Components
import "@spectrum-web-components/styles/typography.css";
import "@spectrum-web-components/theme/express/theme-light.js";
import "@spectrum-web-components/theme/express/scale-medium.js";
import "@spectrum-web-components/theme/sp-theme.js";


// Import Spectrum Web Components
import "@spectrum-web-components/button/sp-button.js";
import "@spectrum-web-components/button-group/sp-button-group.js";
import "@spectrum-web-components/divider/sp-divider.js";
import "./style.css";


// Import the Adobe Express Embed SDK
await import("https://cc-embed.adobe.com/sdk/v4/CCEverywhere.js");
console.log("CCEverywhere loaded", window.CCEverywhere);


// Parameters for initializing the Adobe Express Embed SDK
const hostInfo = {
  clientId: import.meta.env.VITE_API_KEY,
  appName: "Embed SDK Sample",
};


// Initializing the Adobe Express Embed SDK
const { module } = await window.CCEverywhere.initialize(hostInfo, {});


// Will hold the project ID when a document is saved on Adobe Express
var existingProjectId = null;
var expressImage = document.getElementById("savedImage");


// Callbacks to be used when creating or editing a document
const callbacks = {
  onCancel: () => {},
  onPublish: (intent, publishParams) => {
    existingProjectId = publishParams.projectId;
    console.log("Project ID", existingProjectId);
    expressImage.src = publishParams.asset[0].data;
    console.log("Image data", publishParams.asset[0].data);
  },
  onError: (err) => {
    console.error("Error!", err.toString());
  },
};


// Configuration for the app, shared by both Create and Edit flows
const appConfig = {
  appVersion: "2",
  featureConfig: { "community-wall": true },
  thumbnailOptions: ["rich-preview","edit-dropdown"],
  editDropdownOptions: [
    { option: "add-effects" },
    { option: "remove-background" },
    { option: "apply-adjustment" },
    { option: "insert-object" },
    { option: "remove-object" },
  ],
  callbacks,
};


// Configuration for the export options made available to the user
// when creating or editing a document
const exportConfig = [
  {
    id: "download", label: "Download",
    action: { target: "download" }, style: { uiType: "button" }
  },
  {
    id: "save-modified-asset", label: "Save image",
    action: { target: "publish" }, style: { uiType: "button" }
  },
];


// Click handler for the Create Design button
document.getElementById("generateBtn").onclick = async () => {
  module.createImageFromText(appConfig, exportConfig);
};

3.4 Deal with new Intents

When adding the Edit dropdown menu to each generated image (via the "edit-dropdown" option in the thumbnailOptions array, and selecting specific editDropdownOptions), users will be allowed to further edit the image. Technically, they will jump from the Generate Image to the Edit Image experience.

Generate image edit image

Whenever users transition from one design workflow to another, Embed SDK will invoke the onIntentChange() callback to inform you about the change. You can use this opportunity to configure the new intent by passing appConfig, exportConfig, or any other relevant settings. These configurations are applied while launching the new intent; if missing, the default settings will be used.

The callback receives two parameters, the oldIntent and the newIntent, both of type ActionIntent. In our specific case, the oldIntent will be ModuleIntent.CREATE_IMAGE_FROM_TEXT and the newIntent will be a ModuleIntent.EDIT_IMAGE.

Copied to your clipboard
// main.js
//... previous code ...


const callbacks = {
  onCancel:  ()                          => { /* ... */ },
  onPublish: (intent, publishParams)     => { /* ... */ },
  onError:   (err)                       => { /* ... */ },
  // 👇
  onIntentChange: (oldIntent, newIntent) => {
    console.log("Intent changed from", oldIntent, "to", newIntent);
    return {
      appConfig:       { /* ... */ },
      exportConfig:    [ /* ... */ ],
      containerConfig: { /* ... */ }
    }
  },
};

Generate image intent change

You may want to use the onIntentChange() callback to, say, configure different Export buttons that better suit the new intent. Please note that subscribing to the callback is totally optional.

4. Customize the Community Wall

The Community Wall is able to showcase custom images instead of the Firefly's publicly available gallery. This is ideal if your users need to generate specific subjects (say, sports team's crests, logos, etc.), and would appreciate a more relevant starting point.

4.1 Enable the Custom Community Wall

To enable the Custom Community Wall, you need to supply a communityWallConfig object to appConfig when you launch Generate Image v2.

Copied to your clipboard
const appConfig = {
  appVersion: "2",
  featureConfig: {
    "community-wall": true, // 👈 turn the wall on
  },
  communityWallConfig: {
    // 👇 your own data-loader
    fetchCommunityAssets: myFetchCommunityAssets,
  },
};

4.2 Provide your own data-loader

The fetchCommunityAssets property is nothing but a callback function that you need to implement, designed to fetch a list of your assets in a paginated way.

The function is called with a limit and cursor parameters. The limit is the number of assets to retrieve at any given time, and the cursor is used to keep track of the batch of assets to fetch next.

The cursor defaults to "Start_Page" on the first call, and you can send "Last_Page" when there are no more custom assets to fetch. At that point, the module will stop asking for more data.

The fetchCommunityAssets callback signature

Copied to your clipboard
async function myFetchCommunityAssets(
  limit: number,
  cursor: string // "Start_Page" on the first call, "Last_Page" on the last call
): Promise<CommunityWallAssetReponse> {
  /* …fetch and return your data… */
}

The fetchCommunityAssets asynchronous callback should return a Promise that resolves to a CommunityWallAssetReponse object.

Copied to your clipboard
interface CommunityWallAssetReponse {
  assets: CommunityWallAssetData[];
  cursor: string; // The cursor for the next page of assets.
}

The Asset schema

The assets array contains the asset objects to display in the Community Wall.

Copied to your clipboard
interface CommunityWallAssetData {
  assetId: string;          // Asset ID for the community asset
  title: string;            // Prompt for the thumbnail item
  height: number;           // Height of the thumbnail image
  width: number;            // Width of the thumbnail image
  thumbnailSrc: string;     // Source of the thumbnail image (base64 string)
  fullRenditionSrc: string; // Source of the full rendition image
                            // for one-up view (base64 string)
  ownerInfo?: {             // Optional: Information about the owner
    name: string;           // Owner's display name
    imgSrc: string;         // Source URL of the owner's image
  };
}

For more information about the aspect ratio of the assets, please refer to the Generate Image v2 Concepts guide.

4.3 Implement the fetchCommunityAssets callback

Now that we know how to provide assets for the Custom Community Wall, let's implement it in our sample project. As follows, the final result.

Generate image Custom Community Wall

In the src/images folder, you'll find 24 images of cats enjoying some leisure time that have been generated with Adobe Firefly, alongside with an images.json file.

Copied to your clipboard
// images/images.json
[
  {
    "file": "Firefly_A cat on a leather armchair sipping various cocktails 232431.jpg",
    "prompt": "A cat on a leather armchair sipping various cocktails"
  },
  {
    "file": "Firefly_A cat on a leather armchair sipping various cocktails 349610.jpg",
    "prompt": "A cat on a leather armchair sipping various cocktails"
  },
  ...
]

The file property is the name of the image file, and the prompt is the prompt used to generate it. We'll use this file to fetch the assets for the Custom Community Wall.

We've created a separate community-wall.js module to handle everything.

  • The "uuid" module (the only external dependency) is a handy helper to assign a unique assetId to every thumbnail we feed to the Community Wall.
  • fetchImages(): grabs images/images.json, the tiny manifest that pairs each cat photo with the prompt that generated it. The function returns the parsed JSON or throws if the file can’t be reached.
  • fileToBase64(): fetches an individual image file, converts it to a Base-64 data URL with FileReader, and resolves a promise once the conversion is done. This is the heavy-lifting step that turns our static JPGs into strings the Community Wall, can digest.
  • We implemented a one-time memory cache to avoid hitting the network twice for the same file.
    • _cache: stores { prompt, base64 } pairs so we never hit the network twice for the same file.
    • _cursor: remembers how many images we’ve already served to enable simple, stateless pagination.
    • PAGE_SIZE: set to 12, mirroring Firefly’s default number of wall tiles per “page.”
    • hydrateCache(): lazily builds the cache on first use. It reads the manifest, converts every file to Base-64, then stashes the result in _cache. Subsequent calls return the already-hydrated data immediately.
  • fetchCommunityAssets() is the core function that the Embed SDK actually invokes.
    • It first ensures the cache is loaded (hydrateCache).
    • It resets _cursor when it reaches the end so a fresh Embed SDK session can still show the wall (otherwise it will try to load non-existing images).
    • It slices the next PAGE_SIZE items out of the cache.
    • It maps each slice entry into the schema the SDK expects, adding a freshly minted uuidv4() as assetId. Thumbnail dimensions are hard coded for simplicity.
    • It advances _cursor, then returns { assets, cursor } where cursor is "Interim_Page" until we exhaust the list, after which it switches to "Last_Page" to tell the SDK there’s nothing more to fetch.
  • Generous console.log statements are sprinkled throughout to make it easy to trace the pagination flow and verify that assets are loaded and served as expected.
Copied to your clipboard
import { v4 as uuidv4 } from "uuid";


// Read images/images.json and return its raw data
const fetchImages = async () => {
  const resp = await fetch("images/images.json");
  if (!resp.ok) {
    throw new Error(
      `Could not load images.json - ${resp.status} ${resp.statusText}`
    );
  }
  return resp.json(); // [ {file, prompt}, …]
};


// Convert a single file in /images to a data-URL
const fileToBase64 = async (fileName) => {
  const resp = await fetch(`images/${fileName}`);
  const blob = await resp.blob();


  return new Promise((resolve, reject) => {
    const reader = new FileReader();
    reader.onerror = reject;
    reader.readAsDataURL(blob);
  });
};


// ------------------------------------------------------------------
// one-time cache (so we only hit the network once)
// ------------------------------------------------------------------
let _cache = null; // [{ prompt, base64 }, …]
let _cursor = 0; // how far we have already served
const PAGE_SIZE = 12; // Firefly’s community wall default


const hydrateCache = async () => {
  if (_cache) return _cache; // already loaded


  const meta = await fetchImages(); // from images.json
  const base64List = await Promise.all(
    meta.map((item) => fileToBase64(item.file))
  );
  _cache = base64List.map((b64, idx) => ({
    prompt: meta[idx].prompt,
    base64: b64,
  }));
  return _cache;
};


/**
 * The very first call returns items 0-11, cursor = 'Interim_Page'
 * The second call returns items 12-23, etc.
 * When the last chunk is served, cursor = 'Last_Page'
 * @returns {Promise<{assets: Array, cursor: 'Interim_Page'|'Last_Page'}>}
 */
export const fetchCommunityAssets = async () => {
  console.log("fetchCommunityAssets called!");


  // Implement your logic here to fetch the assets from the database
  const data = await hydrateCache();
  console.log("data", data);


  // If we have already served all available assets (cursor at or past end),
  // start over so that a fresh Embed SDK session can see the community wall.
  if (_cursor >= data.length) { _cursor = 0 }
  console.log("cursor", _cursor);


  // slice next PAGE_SIZE elements
  const slice = data.slice(_cursor, _cursor + PAGE_SIZE);


  const assets = slice.map((item) => ({
    assetId: uuidv4(),
    title: item.prompt,
    thumbnailSrc: item.base64,     // 👈 for simplicity, we're using the
    fullRenditionSrc: item.base64, //    same image for both high/low res
    width: 467,                    // 👈 hard-coded, or swap with
    height: 600,                   //    real metadata if you like
  }));


  _cursor += slice.length;
  const cursor = _cursor >= data.length ? "Last_Page" : "Interim_Page";


  return { assets, cursor };
};

The last thing we need to do is to import the fetchCommunityAssets function in our main.js file.

Copied to your clipboard
// main.js


import { fetchCommunityAssets } from "./community-wall.js";


//... rest of the code ...


const appConfig = {
  appVersion: "2",
  featureConfig: { "community-wall": true },
  communityWallConfig: { fetchCommunityAssets }, // 👈 set the function
  //... rest of the appConfig ...
};


//... rest of the main.js ...

Generate image fetch community assets

Troubleshooting

Common issues

IssueSolution
Error: "Adobe Express is not available"
Check to have entered the correct API Key in the src/.env file as described here.
The Community Wall is not showing
Make sure you've set the fetchCommunityAssets function in the appConfig

Complete working example

Copied to your clipboard
<!doctype html>
<html lang="en">


<head>
  <meta charset="UTF-8" />
  <meta name="viewport" content="width=device-width, initial-scale=1.0" />
  <title>Embed SDK Sample</title>
</head>


<body>
  <sp-theme scale="medium" color="light" system="express">
    <div class="container">
      <header>
        <h1>Adobe Express Embed SDK</h1>
        <sp-divider size="l"></sp-divider>
        <h2>Generate Image Sample</h2>
        <p>
          The <b>Generate Image</b> button generates an image from the current project.
        </p>
      </header>


      <main>
        <img id="savedImage" src="https://placehold.co/300x300?text=Placeholder+Image&font=source-sans-pro"
          alt="Your design will appear here." />
        <sp-button-group>
          <sp-button id="generateBtn">Generate Image</sp-button>
        </sp-button-group>
      </main>
    </div>
  </sp-theme>


  <script type="module" src="./main.js"></script>


</body>


</html>

Need help?

Have questions or running into issues? Join our Community Forum to get help and connect with other developers working with the Adobe Express Embed SDK.

Related resources

Davide Barranca
Last updated 7/10/2025
Was this helpful?

Community

Support

Adobe Developer

  • Privacy
  • Terms of Use
  • Do not sell or share my personal information
  • AdChoices
Copyright © 2025 Adobe. All rights reserved.
